12
3-in-1 TV STAND
www.insigniaproducts.com
Step 6: Attach the bottom subframe to the bottom shelf
1 Insert six 5/8” bolts (T), with lock washers (W) and flat washers (X), through the metal tabs on the bottom
crossbar (D) and the side rails (E and F), then finger tighten them into the threaded holes on the bottom shelf
(K).
2 Tighten the bolts (T) with the 4 mm hex key (EE).
You’ll need:
NS-HWMC1848_17-0157_MAN_V4_ENG.fm Page 12 Tuesday, March 7, 2017 3:08 PM
