www.insigniaproducts.com
11
7 Cu. Ft. Convertible Upright Freezer
6 Move the hole cover from the top left side of the door to the top right side. (Tool needed: B)
7 Remove the freezer door from the freezer by lifting it off the bottom hinge pin, then rest it on a pad to prevent
scratching or damage.
8 Use a Phillips head screwdriver to remove the right side hinge component from the bottom right side of the door. (Tool
needed: A)
9 Take the left-side hinge component out of the accessory bag, then use a Phillips head screwdriver to install it on the
bottom left side of the door. (Tool needed: A)
10 Remove both leveling feet and the bottom hinge bracket from the bottom of your freezer. (Tool needed: C)
