IF1200A Pilot Operating Handbook Appendix
Compass Calibration: QGroundControl (Ardupilot)
Step
Action
8
Repeat the calibration for all aircraft orientations until all orientations have a green
border.
9
Once you've calibrated the vehicle in all the positions, QGroundControl will display
Calibration complete (all orientation images will be displayed in green and the
progress bar will fill completely). You can then proceed to the next sensor if desired.
10
Reboot the aircraft prior to flight.
End of Procedure
