INSTEON wall switch - Scene Control and Mechanical Details

34
Maximum Controlled Scenes 1
Maximum Scene Memberships 1
Multi-Link Support Yes
Multi-Unlink Support Yes
Phase Detect Beacon Yes
Radio Frequency 915.0 MHz US
Radio Frequency Range 150 feet
Scene Commands Supported as
Controller
On O
Fast-On Fast-O
Begin Brighten Begin Dim
End Brighten End Dim
Scene Commands Supported as
Responder
On O
Fast-On Fast-O
Begin Brighten Begin Dim
End Brighten End Dim
Software Congurable Yes
Mechanical
Paddle Type True rocker action
Wire Nuts 4 Included
Mounting Single or multi-gang junction boxes. Derating of 200W for each
immediately adjacent dimmer.
Dimensions On/O and Dimmer Switch
4.1” H x 1.8” W x 1.2” D
104mm x 46mm W x 31mm D
Dimmer Switch (High Wattage)
4.1” H x 2.5” W x 1.2” D
104mm x 64mm W x 31mm D
Operating Environment Indoors
Operating Humidity Range 0-90% relative humidity, non-condensing
Operating Temperature Range -40º to 104º F
-40º to 40º C
Specications
