INSTEON wall switch - Product Overview; Installation Prerequisites

4
Dimmer Switch & On/O Switch High-Wattage Dimmer Switch
Insteon Wall Switch
Tools Needed for Installation Disconnect Power
Set Button Set ButtonHeat Sink Tab
(1000W Only)
O
Hold to Dim
O
Hold to Dim
On
Hold to
Brighten
On
Hold to
Brighten
Brightness
LEDs
Brightness
LEDs
Status LED Status LED
Phillips Screwdriver
Wire Cutter / Stripper
Voltage Detector
Flathead Screwdriver
Always disconnect power before
installation. Contact Insteon
Support when uncertain about
installation.
1-866-243-8022
