35
Product Support: www.instron.com
Chapter 3
Specifications
• 34TM-50 Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
• Accessory Mounting Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
• System Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
34TM-50 Dimensions and Weight
Frame Dimensions
Load frame dimensions for 34TM-50 frames are shown in Figure 3 on page 37 and
Figure 4 on page 38. Some dimensions are listed in Table 7 on page 35 and Table 8
on page 36.
Dimension “C” in Figure 3 on page 37 varies for different load cells, refer to Table 9 on
page 36.
Table 7. 34TM-50 dimensions - standard height
Letter
Designation Description Dimension - mm (inch)
D Overall height 1604 (63.1)
B2 Maximum vertical test space (test daylight - from
base to underside of crosshead)
1198 (47.2)
B1 Minimum vertical test space (test daylight - from
base to underside of crosshead)
70 (2.8)
A Crosshead thickness 120 (4.7)
