Instron 34TM-50 - Base Beam Dimensions; Crosshead Dimensions

Chapter: Specifications
40 M10-17322-EN
Base beam dimensions
Figure 5. View of base beam from above
Crosshead dimensions
Figure 6. View of underside of crosshead
40.000
40.038
36.50 8.0
280
7X M10 25
140
90
45
5
13
120°
100 PCD
TYP.
3.25
3.00
5.40
5.70
4X 3 5
ON 55 PCD
17 THRU
20.50 3.44
40.000
40.038
50
25
45°
8X M10
20
60°
0 43 140 43 140
3.13
3.00
