5-9
Ancillary Parts
Product Support: www.instron.com
Models 5965 and 5966
Table 5-2. 5965 and 5966 Ancillary Parts
Description
Part
Number Quantity Purpose
Cable tie hook and loop 11-10-1027 5 Cable management
Cable clip, 6-12 mm 11-6-60 3 Secures cables to the frame
Screw, M10 x 70 201R239 1 Attaches 2580 Series load cells
(500N, 1kN, 2kN and 5kN) to 5965
and 5966 frames
Screw, M16 x 80 201R312 1 Attaches 2580 Series load cell (10kN)
to 5966 frame
Screw, M10 x 30 201V55 3 Attaches 2525 Series load cells
Screw, M10 x 40 201V57 3 Attaches 2525 Series load cells
Pin 3mm diameter, 10mm long 705K84 1 Load cell anti-rotation pin
Pin 3mm diameter, 12mm long 705K85 1 Load cell anti-rotation pin
Locating disc T1335-1048 1 Load cell locating ring - 40mm - used
for 2580 Series load cells (500N, 1kN,
2kN, 5kN)
Locating ring adapter T604-101 1 Adapter for load cell locating ring -
40mm/20mm - used for 2580 Series
load cells (10kN, 30kN, 50kN)
M10 spacer T604-90 1 Use with M10 screws for load cell
attachment
M16 washer 610J12 3 Use with M16 screws for load cell
attachment
Fuse, 10A Time lag, 5 x 20mm
glass high surge
27-2-233 2 Protection from electrical surges
Compression spring 66-5-6 1 Removes slack on lower grips with no
checknut
Compression spring
3/4 OD x 2 in length
66-4-5 1 Removes slack on lower grips with no
checknut
Hex wrench key set,
1.5 to 10 mm
80-1-1011 1 Tools for maintaining the frame and
installation of accessories
8 mm bit - 1/2 drive 80-3-13 1 Torquing M10 bolts on various load
string components
