Instron 5967 - Models 5967 and 5969

5-11
Ancillary Parts
Product Support: www.instron.com
Models 5967 and 5969
Locating disc T1335-1048 2 Load cell locating ring - 40mm - used
for 2580 Series load cells (500N, 1kN,
2kN, 5kN)
Locating ring adapter T604-101 1 Adapter for load cell locating ring -
40mm/20mm - used for 2580 Series
load cells (10kN, 30kN, 50kN)
Crosshead Clevis - Type D T1209-1138 1 Connects grips and fixtures to top of
crosshead
Retaining pin, grip coupling T29-515 1 Secures the grip coupling
Converter Type D to Type O 2501-346 1 Allows use of accessories with Type
O interface.
Table 5-2. 5965 and 5966 Ancillary Parts
Description
Part
Number Quantity Purpose
Table 5-3. 5967 and 5969 Ancillary Parts
Description
Part
Number Quantity Purpose
Cable tie hook and loop 11-10-1027 5 Cable management
Cable clip, 6-12 mm 11-6-60 3 Secures cables to the frame
Screw, M10 x 120 201R246 1 Attaches 2580 Series load cells
(500N, 1kN, 2kN and 5kN) to 5967
and 5969 frames
Screw, M16 x 120 201R317 1 Attaches 2580 Series load cells
(10kN, 30kN and 50kN) to 5987 and
5989 frames.
Screw, M10 x 30 201V55 3 Attaches 2525 Series load cells
Screw, M10 x 40 201V57 3 Attaches 2525 Series load cells
Pin 3mm diameter, 10mm long 705K84 1 Load cell anti-rotation pin
Pin 3mm diameter, 12mm long 705K85 1 Load cell anti-rotation pin
Locating disc T1335-1048 1 Load cell locating ring - 40mm - used
for 2580 Series load cells (500N, 1kN,
2kN, 5kN)
