5-13
Ancillary Parts
Product Support: www.instron.com
Additional parts for frames with second test space only:
Screw, M10 x 70 201R239 1 Attaches 2580 Series load cells
(500N, 1kN, 2kN and 5kN) to 5965
and 5966 frames
Screw, M16 x 75 201R311 1 Attaches 2580 Series load cell (10kN)
to 5966 frame
Screw, M10 x 30 201V55 3 Load cell attachment
M10 spacer T604-90 1 Use with M10 screws for load cell
attachment
M16 washer 610J12 1 Use with M16 screws for load cell
attachment
Compression spring
3/4 OD x 2 in length
66-4-5 1 Removes slack on lower grips with no
checknut
Pin 3mm diameter, 10mm long 705K84 1 Load cell anti-rotation pin
Pin 3mm diameter, 12mm long 705K85 1 Load cell anti-rotation pin
Retainer clip for 1/2 diameter pin T1223-1053 1 Prevents the grip coupling pin from
sliding out during testing
Locating disc T1335-1048 2 Load cell locating ring - 40mm - used
for 2580 Series load cells (500N, 1kN,
2kN, 5kN)
Locating ring adapter T604-101 1 Adapter for load cell locating ring -
40mm/20mm - used for 2580 Series
load cells (10kN, 30kN, 50kN)
Crosshead Clevis - Type D T1209-1138 1 Connects grips and fixtures to top of
crosshead
Retaining pin, grip coupling T29-515 1 Secures the grip coupling
Converter Type D to Type O 2501-346 1 Allows use of accessories with Type
O interface.
Table 5-3. 5967 and 5969 Ancillary Parts
Description
Part
Number Quantity Purpose
