Instruction Manual CVM201 Super Bee
InstruTech, Inc. Page 16
6 Display
6.1 Display - Torr / mTorr
The table below shows the displayed readings at various pressures for selected gases when engineering units
selected is in Torr/mTorr.
Displayed Pressure Readings vs. True Pressure for selected gases
Pressures shown in bold italic font in the shaded areas are in mTorr.
Pressures shown in normal font and in non-shaded areas are in Torr.
N
2
Ar He
O
2
CO
2
Kr Freon12 Freon22
D
2
Ne
CH
4
0 mTorr 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
0.1 mTorr 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
0.2 mTorr 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2
0.5 mTorr 0.5 0.5 0.5 0.5 0.5 0.3 0.5 0.5 0.5 0.5 0.5
1 mTorr 1.0 0.7 0.8 1.0 1.1 0.4 1.5 1.5 1.3 0.7 1.7
2 mTorr 2.0 1.4 1.6 2.0 2.3 1.0 3.1 3.1 2.4 1.5 3.3
5 mTorr 5.0 3.3 4.0 5.0 4.4 2.3 7.6 7.0 6.0 3.5 7.7
10 mTorr 10.0 6.6 8.1 9.7 11.0 4.8 14.7 13.5 12.1 7.1 15.3
20 mTorr 20.0 13.1 16.1 19.8 22.2 9.5 29.9 27.2 24.3 14.1 30.4
50 mTorr 50.0 32.4 40.5 49.2 54.9 23.5 72.5 69.0 60.0 34.8 77.2
100 mTorr 100 64.3 82.0 97.2 107 46.8 143 136 121 70.0 159
200 mTorr 200 126 165 194 210 91.1 275 262 250 141 315
500 mTorr 500 312 435 486 489 217 611 594 687 359 781
1 Torr 1.00 600 940 970 950 400 1.05 1.04 1.55 745 1.60
2 Torr 2.00 1.14 2.22 1.94 1.71 700 1.62 1.66 4.13 1.59 3.33
5 Torr 5.00 2.45 13.5 4.98 3.34 1.28 2.45 2.62 246 5.24 7.53
10 Torr 10.0 4.00 OP 10.3 4.97 1.78 2.96 3.39 OP 21.5 27.9
20 Torr 20.0 5.80 OP 22.3 6.59 2.29 3.32 3.72 OP 584 355
50 Torr 50.0 7.85 OP 77.6 8.22 2.57 3.79 4.14 OP OP 842
100 Torr 100 8.83 OP 209 9.25 2.74 4.68 4.91 OP OP OP
200 Torr 200 9.79 OP 295 12.3 3.32 5.99 6.42 OP OP OP
300 Torr 300 11.3 OP 380 16.9 3.59 6.89 7.52 OP OP OP
400 Torr 400 13.5 OP 485 22.4 3.94 7.63 8.42 OP OP OP
500 Torr 500 16.1 OP 604 28.7 4.21 8.28 9.21 OP OP OP
600 Torr 600 18.8 OP 730 36.4 4.44 8.86 9.95 OP OP OP
700 Torr 700 21.8 OP 859 46.1 4.65 9.42 10.7 OP OP OP
760 Torr 760 23.7 OP 941 53.9 4.75 9.76 11.1 OP OP OP
800 Torr 800 25.1 OP 997 59.4 4.84 9.95 11.4 OP OP OP
900 Torr 900 28.5 OP OP 79.5 4.99 10.5 12.0 OP OP OP
1000 Torr 1000 32.5 OP OP 111 5.08 11.1 12.7 OP OP OP
1) OP = overpressure indication: display will read over pressure
2) Display auto-ranges between Torr and mTorr at 1 Torr
Examples:
1) Gas used is nitrogen (N
2
). Display shows pressure measurement of 10 Torr. True pressure of nitrogen is 10 Torr.
2) Gas used is argon (Ar). Display shows pressure measurement of 600 mTorr. True pressure of argon is
1 Torr.
3) Gas used is oxygen (O
2
). Display shows pressure measurement of 486 mTorr. True pressure of oxygen is 500 mTorr.
