3
> Specifications > Advanced Setup > Listening Modes
> Network Functions > Basic Manual
|Troubleshooting Supplementary Information, etc.
Use one of the following Ethernet cables to connect.
Cat6 (Category 6) cable: AWG23 cable or better, 100
m or less in length
Cat5e (Category 5e) cable: AWG24 cable or better,
90 m or less in length
■ Video Inputs
Component
IN1 (BD/DVD), IN2 (GAME)
Composite
IN1 (CBL/SAT), IN2 (STRM BOX)
■ Video Outputs
Component
OUT
■ Compatible input resolutions
HDMI input
4K, 1080p/24, 1080p, 1080i, 720p, 480p/576p
Component input
480i/576i
Composite input
480i/576i
•
The output from the HDMI OUT jack to the TV is the
same resolution as the input.
■ Audio Inputs
Digital
OPTICAL 1 (GAME), 2 (CD), 3 (TV)
COAXIAL 1 (BD/DVD), 2 (CBL/SAT)
Analog
CBL/SAT, STRM BOX, BD/DVD, GAME, CD, TV,
PHONO
■ Audio Outputs
Analog
ZONE2 PRE/LINE OUT
ZONE3 PRE/LINE OUT
PRE OUT (FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R, HEIGHT 1 L/R, HEIGHT 2
L/R, 2 SUBWOOFER)
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R, HEIGHT 1 L/R, HEIGHT 2
L/R
(North American models are banana plug ready)
Phones
PHONES (Front, ø 6.3 mm, 1/4")
■ Others
Setup Mic : 1 (Front)
USB : 1 (Ver. 2.0, 5 V/1 A)
Ethernet : 1
RS232 : 1
IR IN : 2, IR OUT : 1
12V TRIGGER OUT : 3 (A:100 mA, B:25 mA, C:25 mA)
Specifications and features are subject to change without
notice.
