Integra DSR-7.3 Service Manual

DSR-7.3
A
A
To DVDM
CN151
2
8
8
8
12
23
13
17
16
15
14
20
18
19
9
11
10
6
8
Daifree
GEM1036
Lubricating Oil
GYA1001
1a
1c
1b
1d
EXPLODED VIEWS OF MECHANISM-1
DVD MECHANISM:DB-VLD304
PARTS LIST
No. Description Part No. No. Description Part No.
1a
1b
1c
1d
2
6
8
9
10
11
Loading switch PC board
Switch
2P Socket
5p Socket
Traverse mechanism assy
Flexible Cable (26P)
Float Rubber
Belt
Stabilizer
Loading Base
VNP1836
VSK1011
S2B-PH-K
S5B-PH-K
VXX2782
VDA1864
VEB1327
VEB1328
VNE2253
VNL1917
12
13
14
15
16
17
18
19
20
23
Float Base DVD
Drive Cam
Gear Pulley
Loading Gear
Drive Gear
SW Lever
Clamper Plate
Bridge
Clamper
Tray
VNL1918
VNL1919
VNL1921
VNL1922
VNL1923
VNL1925
VNE2251
VNE2252
VNL1924
VNL1920
Refer to
"EXPLODED VIEWS OF MECHANISM-"2
