Integra DSR-7.3 Service Manual

DSR-7.3
12
8
3
7
1
18
18
13
16
19
4
4
17
18
10
10
6
5
5
15
14
9
16
2
17
17
EXPLODED VIEWS OF MECHANISM-2
DVD MECHANISM:DB-VLD304 (TRAVERSE UNIT)
PARTS LIST
Spindle Motor
Stepping Motor
Pickup Assy-S
Skew Screw
Skew Spring
Guide Bar
Sub Guide Bar
Hold Spring
VXM1088
VXM1090
OXX8003
VBA1080
VBH1335
VLL1514
VLL1515
VNC1017
Joint Spring
Support Spring
Mechanism Chassis
Slider
Spacer
Joint
FFC Holder
Screw
Screw
Screw
Damper Sheet
VNC1019
VNC1020
---
VNL1811
VNL1913
VNL1914
VNL1915
BBZ20P050FZK
OBA8009
PMA26P100FMC
VEB1335
No. Description Part No. No. Description Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
(Torgue:0.12 0.01N m)
(Torgue:0.12 0.01N m)
(Torgue:0.12 0.01N m)
Not supplied.
Screw tight
(Adjustment Screw)
(Adjustment Screw)
