REF.NO. PART NO. DESCRIPTION
1 27111275A Front bracket
2 27212379 Front panel
4 838130088 3TTB+8B,Self-tapping screw
5 28135278 Badge
6 838430088 3TTB+8B(BC),Self-tapping screw
7 28326016 Knob, volume
8 27122972A Rear panel
14 27255004 CS-1U,Clip
16 28191961A Clear plate
21 27100418A Chassis
22 27190693A KGLS-6RF,Holder
23 27190428A KGLS-10RF,Holder
24 27190266 KGLS-12RF,Holder
25 27190657 KGLS-18RF,Holder
26 27190369 Holder
31 27160504 heat sink
32 801433 3SMS8W.SW+14B(BC),Special screw
33 830440089 4TTC+8C(BC),Self-tapping screw
33 830440089 4TTC+8C(BC),Self-tapping screw
34 28330135A Cap, screw
36 29110083 Tape, cloth
36 29110083 Tape, cloth
37 27141787 Retainer HP
41 28184835Z Top cover
46 27175319B Leg
47 28141494 Cushion
51 260208 Wire tie
52 223024 AC238,Isolated sheet
53 27190540-1 Holder, clamp
55 27301396 HL-28-0,Clamp
56 28133402 Back plate
58 28325756 Knob,standby
59 28330137 Cap, front
60 28330146 Cap, digital
62 29362609 Label PT
F6901,F6902 252199 ! 10A-UL.Fuse
F901 252198 or ! 8A-UL or
F901 252261 ! 8A-T/UL-ST2,Fuse
F9501 252160 or ! 2.5A-UL/T-237 or
252254 ! 2.5A-T/UL-ST2,Fuse
P101 2047152522 NCFC7-152522,Flexible cable
P6931 2047134512 NCFC7-134512,Flexible cable
P7501 2047113022 NCFC7-113022,Flexible cable
P7502 2047061522 NCFC7-061522,Flexible cable
REF.NO. PART NO. DESCRIPTION
P901 253297KAW ! AS-UC-2,Power supply cord
Q6050~Q605
2202843 or * 2SC5242-O or
2202842 * 2SC5242-R,Transistor
Q6053~Q605
2203663, * MN130S-O,
2203664, * MN130S-Y,
2203666, * MN130S-P,
2202843 or * 2SC5242-O or
2202842 * 2SC5242-R,Transistor
Q6060~Q606
2202833 or * 2SA1962-O or
2202832 * 2SA1962-R,Transistor
Q6063~Q606
2203673, * MP130S-O,
2203674, * MP130S-Y,
2203676, * MP130S-P,
2202833 or * 2SA1962-O or
2202832 * 2SA1962-R,Transistor
T901 2301584 ! NPT-1438D,Power transformer
U1 1A929560-1F NADG-7460-1F,Main circuit PC board ass'y
U2 1A929561-1D NADIS-7461-1D,Display circuit PC board ass'y
U3 1A929562-1D NASW-7462-1D,Volume PC board ass'y
U4 1A929563-1D NAETC-7463-1D,Headphone terminal PC board ass'y
U5 1A929564-1D NAVD-7464-1D,Video terminal PC board ass'y
U6 1A929565-1D NAVD-7465-1D,Component video terminal PC board ass'y
U7 1A929566-1D NAETC-7466-1D,A-bus circuit PC board ass'y
U9 1A929568-1D NAVD-7468-1D,Front video PC board ass'y
U10 1A929569-1D NAETC-7469-1D, RC-232C terminal PC board ass'y
U11 1A929570-1D NADG-7470-1D,Front optical input PC board ass'y
U12 1A929571-1D NAETC-7471-1D,PC board for holder
U13 1A929572-1D NAETC-7472-1D,PC board for holder
U15 1A929574-1C NAAF-7474-1C,Power amplifier PC board ass'y
U16 1A929576-1C NAETC-7476-1C,Speaker terminal PC board ass'y
U17 1A929577-1C NAPS-7477-1C,Secondary circuit PC board ass'y
U19 1A929579-1C NAETC-7479-1C,PC board for holder
U20 1A929580-1C NAETC-7480-1C,Thermal detector PC board ass'y
U21 1A929581-1C NAETC-7481-1C,PC board for holder
U23 1A929583-1H NAAF-7483-1H,Driver circuit PC board ass'y
U24 1A929584-1H NAPS-7484-1H,Primary circuit PC board ass'y
U26 1A929586-1H NAETC-7486-1H,Connector PC board ass'y
U29 1A929589-1H NAPS-7489-1H,Terminal PC board ass'y
U30 1A929590-1H NAETC-7490-1H,AC inlet PC board ass'y
U31 1A929591-1H NAETC-7491-1H,PC board for holder
U32 1A929592-1H NAETC-7492-1H,PC board for holder
U36 240141, FAE350-A13F,
240134A or TFCE1U114B or
240138A ENG06501QR,Tuner unit
DTR-5.3
EXPLODED VIEW-PARTS LIST
DTR-5.3
