PRIMARY CIRCUIT PC BOARD (NAPS-7484-1H)
CIRCUIT NO. PART NO. DESCRIPTION
Transistor
Q921 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diodes
D921~D924 22380260 or RL1N4003 or
22380035 GP104003E
D925 223163, 1SS133,
223205 or 1SS270A or
Power transformer
T902 2301381 ! NPT-1358D
Capacitors
C901 3500196S ! RE275V-103M,IS
C922 394662217 220uF,35V,Elect.
C923 374722234 0.022uF+/-5%,50V,Plastic
Resistors
R901 4000206S ! RD1/2SPH-3.3M,Solid
R924 443528204 82ohm+/-5%,1/2W,Metal oxide
AC outlet
P902 25051126 ! NSCT-4P913
Relay
RL901 25065561, ! NRL-1P5A-DC12-127,
25065508, ! NRL-1P10A-DC12-093,
25065515 or ! NRL-1P5A-DC12-096 or
25065526 ! NRL-1P5A-DC12-102
RL901 25065584 or ! NRL-1P10A-DC12-140 or
25065516 ! NRL-1P10A-DC12-097
Fuse holders
F901A,F901B 25052133 ! NSCT-1P2031
Socket
P931A 25051230 NSCT-5P1020
Plug
P901A 25055675 or ! NPLG-2P631 or
25056028 ! NPLG-2P0978
CONNECTOR PC BOARD (NAETC-7486-1H)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q2031,Q2032 2215960 or KRC102M or
Q2225 2213290 DTC114ES
Q2231,Q2232 2215770 or KRA102M or
Q2234,Q2236 2213510 DTA114ES
Q2233,Q2235 2215770 or KRA102M or
2213510 DTA114ES
Capacitors
C2244 394644707 47uF,16V,Elect.
C2245 374722244 0.22uF+/-5%,50V,Plastic
Themistors
R2248 4000195 RXE030
Sockets
P105A 25051237 NSCT-12P1027
P105A 25051241 NSCT-20P1031
P106A 25051235 NSCT-10P1025
P107A 25051240 NSCT-15P1030
P205A 25055712 NPLG-20P668
P207A 25055708 NPLG-12P664
P2207A 25055711 NPLG-15P667
P5504 25137486 NCETC-7486
AC INLET PC BOARD (NAETC-7490-1H)
CIRCUIT NO. PART NO. DESCRIPTION
AC Inlet
P901B 25055960 ! NPLG-2P913
DTR-5.3
PRINTED CIRCUIT BOARD-PARTS LIST 6
