DTR-6.5
C9010 394644727S CE04W16V-4700M(VR),Elect.
C9011 394651027S CE04W25V-1000M(VR),Elect.
C9012,C9015,C9016 335622230 CK45F50V-223Z,Ceramic
C9013 394641007 CE04W16V-10M(VR),Elect.
C9014 394674717S CE04W63V-470M(VR),Elect.
C9017 374721024 ECQ-B50V-102J,Plastic
Resistors
R9002 443522204 RS1/2WBJ-22,Metal oxide
R9003,R9004 417348224 R16J-8.2K,Carbon
R9005 417343334 R16J-33K,Carbon
R9006 453530474 RNU1/2WCJ-4.7,Metal
Sockets
JL9501B,JL9502A 25051111 NSCT-7P898
P6931A 25052532 or NSCT-11P2429 or
25052348 NSCT-11P2245
P6953B 25051528 NSCT-17P1315
P7502B 25052244 NSCT-11P2141
Screw
D9002B 838430107 3TTB+10S(BC)
Radiator
D9005A 27160211 RAD-68
Fuse terminal PC board (NAETC-8390-1J/1K)
CIRCUIT NO. PART NO. DESCRIPTION
Capacitor
C9591 374721044 ECQ-V50V-104J
Resistors
R9591,R9592 453530104 RNU1/2WCJ-1
R9594 453530224 RNU1/2WCJ-2.2
Fuse holders
F9501A,F9501B 25052133 NSCT-1P2031
Label
F9501C 29361747 T2.5AL250V
Socket
JL9501A 25051111 NSCT-7P898
Power amplifier PC board (NAAF-8391-1J/1K)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q6015,Q6016 2213284 or 2SC1740S-R or
Q6025,Q6026 2213285 2SC1740S-S
Q6035,Q6036 2203010 or 2SC5171 or
