DTR-6.5
PRINTED CIRCUIT BOARD-PARTS LIS
NOTE: THE COMPONENTS IDENTIFIED BY MARK !
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
CAUTION: Replacement for transistor of mark *, if necessary
must be made from the same beta group (h
FE) as
the original type.
NOTE:
<D>:120V model only <A>:Australian model only
DSP and preamplifier PC board (NAAR-8365-1F/1G)
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q201 22242165R3 CS494003CQZ(CSSS)
Q202 22242123R3 or IC42S16100 or
22242152R2 or K4S161622H-UC60 or
22242123R2 IC42S16100
Q203 222W0002R301386 MX29LV040TC-90(0138)
Q301,Q306,Q307 22241383R2 or NJM4565M-D or
22240581R2 NJM4565M
Q302 22242193R3 NJW1157B (After change)
Q303 222780073R2 78L07(SMT)
Q304 222790073R2 79L07(SMT)
Q305 22242099R2 TC9162BFG
Q421 22242157R2 BD3814FV
Q501,Q502,Q503 22241383R2 or NJM4565M-D or
Q504,Q505,Q506 22240581R2 NJM4565M
Q507,Q508,Q509 22241383R2 or NJM4565M-D or
Q510,Q511,Q512 22240581R2 NJM4565M
Q513,Q514 22241383R2 or NJM4565M-D or
Q515,Q516 22240581R2 NJM4565M
Q651,Q652 22241383R2 or NJM4565M-D or
22240581R2 NJM4565M
Q653,Q654 22241943R2 CS5333-KZ
Q681 22274541ER2TO or TC74VHC541FT or
22274541IR2TI SN74AHC541PWR
Q682 222740077R2TO TC74HCT7007AF
Q861 22242168R3 or CS42518-CQZR-C or
22242168R2 CS42518-CQZR-C
Q862 22240935R2 TC7WU04FU
Q901 222780124TOS or TA7812S or
222780125 78M12HF
