DTR-6.5
SPECIFICATIONS
Amplier Section
Video Section
Tuner Section
FM
AM
General
Video Inputs
Video Outputs
Audio Inputs
Audio Outputs
Other Jacks
Specifications and features are subject to change without
notice.
Power Output
(2 channels driven): 100 W + 100 W (8 ,20Hz–20kHz,FTC)
130 W + 130 W (6 ,1kHz,DIN)
160 W + 160 W (6 ,1kHz,JEITA)
Dynamic Power 230 W + 230 W (3 ,Front)
170 W + 170 W (4 ,Front)
115 W + 115 W (8 ,Front)
THD (Total Harmonic
Distortion) 0.08 % (Power Rated)
Damping Factor 60 (Front,1kHz,8 )
Input Sensitivity and
Impedance 200 mV/ 47 k (LINE)
2.5 mV/ 4.7 k (PHONO MM)
Output Level and
Impeadance 200 mV/ 470 (REC OUT)
Phono Overload 70 mV (MM 1kHz 0.5 %)
Frequency Response 10 Hz–100 kHz/ +1 dB-3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 10 kHz (TREBLE)
SN Ratio 106 dB (LINEIHF-A)
80 dB (PHONO,IHF-A)
Speaker Impedance American : 6
~
other :4 ~
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75 (Component and S-Video Y)
0.7 Vp-p /75 (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75 (S-Video C)
1 Vp-p /75 (Composite)
Component Video
Frequency Response 5 Hz – 50 MHz
Tuning Frequency RangeAmerican: 87.5 MHz– 107.9 MHz
Other : 87.5 MHz– 108.0 MHz
Usable Sensitivity Stereo; 17.2 dBf 2 µV(75 IHF)
Mono; 11.2 dBf 1 µV(75 IHF)
S/N Ratio Stereo; 70 dB (IHF-A)
Mono; 76 dB (IHF-A)
THD Stereo; 0.3 % (1kHz)
Mono 0.2 % (1kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 45 dB ( 1kHz )
Tuning Frequency RangeAmerican: 530 kHz–1700 kHz
Others: 522 kHz–1611 kHz
Usable Sensitivity 30 µV
S/N Ratio 40 dB
THD 0.70%
Power Supply American: AC 120 V, 60 Hz
Australian: AC 230-240 V, 50 Hz
Power Comsumption American : 8.1A
Others : 700 W
Stand-by Power
Comsumption 1.0 W
Dimensions(W x H x D) 435 W x 175 H x 428 D mm
17-1/8" W x 6-7/8" H x 16-7/8" D inches
Weight 15.2 kg
33.5 lbs
Component Video Input 1,2,3
S-Video Compatible Jack
Inputs DVD,VIDEO1,VIDEO2,VIDEO3,
VIDEO4
A/V Inputs DVD,VIDEO1,VIDEO2,VIDEO3,
VIDEO4
Component Video
Output OUT
S-Video Compatible Jack
Outputs MONITOR OUT,VIDEO1,VIDEO2
A/V Outputs MONITOR OUT,VIDEO1,VIDEO2
Digital Inputs Optical : 5 , 1 (Front Panel )
Coaxial : 2
Analog Inputs DVD(MULTICHANNEL),VIDEO1,VID
EO2,VIDEO3,VIDEO4,TAPE,CD,PHO
NO
Multichannel Inputs 6
Digital Outputs Optical : 1
Coaxial : 1
Analog Outputs TAPE,VIDEO1,VIDEO2
Multichannel Pre
Outputs 7
Subwoofer Pre Output 1
Speaker Outputs 9
Phones 1
RS-232 Control 1
IR Input/Output 1
12V Trigger Out
