DTR-6.5
P2501B 25055371 NPLG-7P354
Front optical terminal PC board (NADG-8410-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
Photo coupler
U2601 24120108 GP1FA513RZ
Coil
L2601 233533M022R2 or NCH-1587-022M or
231237M022R2 NCH-1471
Capacitors
C2601 394621017 or CE04W6.3V-100M(VR) or
394721017 CE04W6.3V100M(SC),Elect.
C2602 332161040R1 CK725F1E-104Z1,Chip ceramic
Resistor
R2601 435032214R1 RN72K1J-221JE,Chip carbon
Socket
JL7503A 25051087 NSCT-3P874
Volume PC board (NASW-8411-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
C7515,C7516 332161040R1 CK725F1E-104Z1,Chip ceramic capacitor
S7502 25065611 EC16B24C25,Rotary encoder
JL7501B 25051089 NSCT-5P876,Socket
Headphone terminal PC board (NAETC-8412-1D/1E)
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q7801 22241383R2 NJM4565M-D
Transistor
Q7802 2213631 RN1241-A
Diode
D7801 224470562 MTZJ5.6B
Coils
L7701,L7703 233533M022R2 or NCH-1587-022M or
L7704 231237M022R2 NCH-1471
L7801,L7802 233533M022R2 or NCH-1587-022M or
L7803,L7804 231237M022R2 NCH-1471
Capacitors
C7701,C7702 342111024R1 CC725CH1E-102J1,Chip ceramic
C7703 374722215 ECQ-B50V-221K,Plastic film
