DTR-6.5
Q904C,Q909C 223034 MT-25
Heat sink
Q901B 27160500 RAD-165
Screws
Q901A,Q904A 82143010 3P+10FN(BC),Pan head
Q909A,Q910A 82143010 3P+10FN(BC),Pan head
Main connector PC board (NADG-8366-1F/1G)
CIRCUIT NO. PART NO. DESCRIPTION
ICs
Q701 22242234R3 M30627MHP-233GP(MASK)
Transistors
Q702,Q705,Q707 2216210R2 or KRC104S or
Q709,Q711 2214490R2 RN1404
Q703,Q704,Q706 2216220R2 or KRA102S or
Q708 2214530R2 RN2402
Diodes
D701,D702,D703 223234R2 or 1SS352 or
D705,D706,D708 223269R2 1SS355
D704,D707,D709 224660514R2 or HZU5.1B or
224550510R2 UDZS5.1B
D711 224551300R2 or UDZS13B or
224661304R2 HZU13B
Oscillator
X701 3010397R2 CSTCR6M0055-R0
Choke coil
L701 233533K470R2 or NCH-1587-470K or
231237K470R2 NCH-1479
Capacitors
C701,C702,C703 394680107 or CE04W50V-1M(VR) or
C707 394780107 CE04W50V1.0M(SC),Elect.
C704 3000126 or FM0H224Z or
3000079 DX-5R5L224,Super
C705 332121045R1 CK725B1C-104K1,Chip ceramic
C706 332161040R1 CK725F1E-104Z1,Chip ceramic
C708,C709,C710 332161040R1 CK725F1E-104Z1,Chip ceramic
C711,C712 332161040R1 CK725F1E-104Z1,Chip ceramic
C714,C715,C716 342111024R1 CC725CH1E-102J1,Chip ceramic
C717,C718,C719 342111024R1 CC725CH1E-102J1,Chip ceramic
C720,C721,C722 342111024R1 CC725CH1E-102J1,Chip ceramic
C723,C724 342111024R1 CC725CH1E-102J1,Chip ceramic
C725,C741 394641007 or CE04W16V-10M(VR) or
