DTR-6.5
C129 332161040R1 CK725F1E-104Z1,Chip ceramic
Resistors
R102,R103,R104 435033314R1 RN72K1J-331JE,Chip carbon
R105,R123,R124 435033314R1 RN72K1J-331JE,Chip carbon
R111,R112 435037504R1 RN72K1J-750JE,Chip carbon
R113,R114 435031004R1 RN72K1J-100JE,Chip carbon
R115,R116 435032244R1 RN72K1J-224JE,Chip carbon
R117,R118,R119 435031034R1 RN72K1J-103JE,Chip carbon
R122 435031044R1 RN72K1J-104JE,Chip carbon
R125,R126 435033314R1 RN72K1J-331JE,Chip carbon
Terminals
P111 25045624 NPJ-3PDO431
Sockets
P101 25052379 NSCT-9P2277
P120A 2009990917UL NSAS-24P1446
Primary circuit PC board (NAPS-8382-1J/1K)
CIRCUIT NO. PART NO. DESCRIPTION
Transistors
Q921 2215864 or KTC3199-GR or
2213284 or 2SC1740S-R or
2213285 or 2SC1740S-S or
2212115 2SC2458-GR
Diodes
D921,D922 22380260 or RL1N4003 or
D923,D924 22380035 GP104003E
D925 223163 or 1SS133 or
223205 or 1SS270A or
223222 WG713A
Capacitors
C901 3800039S or ! ECQU2A103MLC or
3500196S ! RE275V-103M,IS
C921 335622230 CK45F50V-223Z,Ceramic
C922 394654717 CE04W25V-470M(VR),Elect.
C923 335321025 CK45B50V-102K,Ceramic
Resistors
R921 453630824 RNU1WCJ-8.2,Metal
R922 417341034 R16J-10K,Carbon
R923 417341024 R16J-1K,Carbon
R926 417344724 R16J-4.7K,Carbon
Power transformer
T902 2301775 ! NPT-1504D <D>
