DTR-7.2
PRINTED CIRCUIT BOARD-PARTS LIST 2
PRIMARY CIRCUIT PC BOARD (NAPS-7233-1T)
CIRCUIT NO. PART NO. DESCRIPTION
Transistor
Q921 2215864, KTC3199-GR,
2212115, 2SC2458-GR,
2213284 or 2SC1740S-R or
2213285 2SC1740S-S
Diodes
D921-D924 22380260, RL1N4003,
22380032 or 1SR139-100 or
22380035 GP104003E
D925 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Power transformer
T902 2300670A NPT-1111D
Capacitors
C901 3500196S RE275V-103M
C902 3300030 DE1307E472M-KH
C922 354762219 220uF,35V,Elect.
Resistors
R901 431533355 RC1/2GFKUL-3.3M
R924 443521804 18ohm+/-5%,1/2W,Metal oxide
Relay
RL901 25065584,
NRL-1P10A-DC12-140,
25065516 or
NRL-1P10A-DC12-097 or
25065588
NRL-1P10A-DC12-143
AC outlet
P902 25051126
NSCT-4P913
Fuse
F901 252196
10A-UL, Fuse
Fuse holders
F901A,F901B 25052133
NSCT-1P2031
Socket
JL931B 25050267
NSCT-3P95
Plug
P911 25055675 or
NPLG-2P631 or
25056028
NPLG-2P0978
RECTIFIER CIRCUIT PC BOARD (NAPS-7234-1T)
CIRCUIT NO. PART NO. DESCRIPTION
Diodes
D6901,D6902 22380260, RL1N4003,
22380032 or 1SR139-100 or
22380035 GP104003E
D6903,D6904 22380309 or D15XB60 or
22380044 RBV-1506
D6906 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Capacitors
C6903 374722234 0.022uF+/-5%,50V,Plastic
C6908-C6911 374733344 0.33uF+/-5%,100V,Plastic
C6915,C6916 374733344 0.33uF+/-5%,100V,Plastic
Relays
RL6901,RL6902 25065584, NRL-1P10A-DC12-140,
25065516 or NRL-1P10A-DC12-097 or
25065588 NRL-1P10A-DC12-143
Fuses
F6901,F6902
252199
10A-UL, Fuse
SPEAKER TERMINAL F/C PC BOARD (NAETC-7236-1T)
CIRCUIT NO. PART NO. DESCRIPTION
Diode
D6600 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Capacitors
C6830-C6832 374731034 0.01uF+/-5%,100V,Plastic
Resistors
R6830-R6832 453630824 8.2ohm+/-5%,1W,Metal
Relays
RL6600,RL6602 25065563, NRL-2P5A-DC24-129,
25065517 or NRL-2P5A-DC24-098 or
25065586 NRL-2P5A-DC24-142
Terminal
P6800 25060309 NTM-6PDMN240
Plugs
P6008A 25055167 NPLG-4P151
P6810D 25055166 NPLG-3P150
P6830 25055734 NPLG-3P690
SPEAKER TERMINAL SR/SB PC BOARD (NAETC-7237-1T)
CIRCUIT NO. PART NO. DESCRIPTION
Diodes
D6603,D6605 223163, 1SS133,
223205 or 1SS270A or
223222 WG713A
Capacitors
C6833,C6834 374731034 0.01uF+/-5%,100V,Plastic
C6836 374731034 0.01uF+/-5%,100V,Plastic
Resistors
R5613 453530474 4.7ohm+/-5%,1/2W,Metal
R6833-R6836 453630824 8.2ohm+/-5%,1W,Metal
Relays
RL6603,RL6605 25065563, NRL-2P5A-DC24-129,
25065517 or NRL-2P5A-DC24-098 or
25065586 NRL-2P5A-DC24-142
Terminal
P6802 25060309 NTM-6PDMN240
Plugs
P6008B 25055169 NPLG-6P153
P6812E 25055168 NPLG-5P152
P6832 25055734 NPLG-3P690
P6931 25055701 NPLG-5P657
Terminals
P5100,P5101 25060302 NTM-1P233(M1969)
Sockets
P6000A-P6002A 25052287 NSCT-4P2184
P6010A 25052289 NSCT-6P2186
P6011A,P6012A 25052287 NSCT-4P2184
CIRCUIT NO. PART NO. DESCRIPTION
CIRCUIT NO. PART NO. DESCRIPTION
Fuse holders
F6901A,F6901B 25052133 NSCT-1P2031
F6902A,F6902B 25052133 NSCT-1P2031
Socket
JL6953B 25050268 NSCT-4P96
Plugs
P6401 25055042 NPLG-3P32
P6951 25055172 NPLG-9P156
P6952A 25055168 NPLG-5P152
P9505A 25055600 NPLG-2P568
Radiator
D6903A 27160483 RAD-152
Screws
D6903B,D6904B 82143010 3P+10FN(BC)
Spring washers
D6903C,D9604C 871430 SW-3(BC)
POWER SWITCH PC BOARD (NASW-7235-1T)
CIRCUIT NO. PART NO. DESCRIPTION
S906 25035636 NPS-111-L590P,Push switch
!
!
!
!
!
!
!
!
!
!
!
