Page #12 background imageLoading...
Page #12 background image
7
Jumper
Jumper Name Description
JBAT CMOS RAM Clear Function Setting 3-pin Block
JP1 INVERTER1 VCC 3.3V/5V/12V Select 4-pin Block
JP2 LVDS1 VCC 3.3V/5V/12V Select 4-pin Block
JCOMP3 COM3 Header Pin9 Function Select 4-Pin Block
JCOMP2 COM2 Header Pin9 Function Select 4-Pin Block
JCOMP1 COM1 Header Pin9 Function Select 4-Pin Block
JCOM1 COM1 Header RS232/RS485/RS422 Select 6-Pin Block
AT_MODE1 AT MODE Function Select 2-pin Block
Connectors
Connector Name
DCIN1 ATX 12V Power Connector
COM1 Serial Port Connector
VGA Video Graphic Attach Connector
USB1 USB 2.0 Port Connector x2
LAN1/LAN2 RJ-45 LAN Connector x2
AUDIO2 Audio Line-Out Connector
SATA1/2 SATAII Connector x2
PWOUT1 SATA Power out Connector
MINI_CARD Half-size Mini-PCIE Connector
MSATA Mini-SATA Connector
