Headers
Header Name Description
JW_FP1
Front Panel Header(PWR LED/ HD
LED/Power Button /Reset)
8-pin Block
USB2/USB3 USB 2.0 Port Header 9-pin Block
COM2/3/4/5/6 Serial Port Header 9-pin Block
TX_RXCOM1 TX_RXCOM1 Header
PARALLEL1 Parallel Port Header 25-pin Block
GPIO1 GPIO Header 10-pin block
VGA1 VGA Header 12-pin Block
HDMI1 HDMI Header 20-pin Block
LVDS1 LVDS Header 30-pin Block
INVERTER1 LVDS Inverter 6-pin Block
SPEAKER_CON Speaker Header 4-pin Block
JP3 LVDS Panel Brightness
Adjustment
Header
2-pin Block
CPUFAN FAN Header 4-pin Block
SYSFAN1/SYSFAN3
SYSFAN Headers 3-pin Block
