Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU - Voltage Identification Definition

18 Datasheet
Electrical Specifications
Table 2-2. Voltage Identification Definition
VID5 VID4 VID3 VID2 VID1 VID0 VID VID5 VID4 VID3 VID2 VID1 VID0 VID
0 0 1 0 1 0 0.8375 0 1 1 0 1 0 1.2125
1 0 1 0 0 1 0.8500 1 1 1 0 0 1 1.2250
0 0 1 0 0 1 0.8625 0 1 1 0 0 1 1.2375
1 0 1 0 0 0 0.8750 1 1 1 0 0 0 1.2500
0 0 1 0 0 0 0.8875 0 1 1 0 0 0 1.2625
1 0 0 1 1 1 0.9000 1 1 0 1 1 1 1.2750
0 0 0 1 1 1 0.9125 0 1 0 1 1 1 1.2875
1 0 0 1 1 0 0.9250 1 1 0 1 1 0 1.3000
0 0 0 1 1 0 0.9375 0 1 0 1 1 0 1.3125
1 0 0 1 0 1 0.9500 1 1 0 1 0 1 1.3250
0 0 0 1 0 1 0.9625 0 1 0 1 0 1 1.3375
1 0 0 1 0 0 0.9750 1 1 0 1 0 0 1.3500
0 0 0 1 0 0 0.9875 0 1 0 1 0 0 1.3625
1 0 0 0 1 1 1.0000 1 1 0 0 1 1 1.3750
0 0 0 0 1 1 1.0125 0 1 0 0 1 1 1.3875
1 0 0 0 1 0 1.0250 1 1 0 0 1 0 1.4000
0 0 0 0 1 0 1.0375 0 1 0 0 1 0 1.4125
1 0 0 0 0 1 1.0500 1 1 0 0 0 1 1.4250
0 0 0 0 0 1 1.0625 0 1 0 0 0 1 1.4375
1 0 0 0 0 0 1.0750 1 1 0 0 0 0 1.4500
0 0 0 0 0 0 1.0875 0 1 0 0 0 0 1.4625
1 1 1 1 1 1 VR output off 1 0 1 1 1 1 1.4750
0 1 1 1 1 1 VR output off 0 0 1 1 1 1 1.4875
1 1 1 1 1 0 1.1000 1 0 1 1 1 0 1.5000
0 1 1 1 1 0 1.1125 0 0 1 1 1 0 1.5125
1 1 1 1 0 1 1.1250 1 0 1 1 0 1 1.5250
0 1 1 1 0 1 1.1375 0 0 1 1 0 1 1.5375
1 1 1 1 0 0 1.1500 1 0 1 1 0 0 1.5500
0 1 1 1 0 0 1.1625 0 0 1 1 0 0 1.5625
1 1 1 0 1 1 1.1750 1 0 1 0 1 1 1.5750
0 1 1 0 1 1 1.1875 0 0 1 0 1 1 1.5875
1 1 1 0 1 0 1.2000 1 0 1 0 1 0 1.6000
