Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU User Manual

Datasheet 43
Land Listing and Signal Descriptions
4 Land Listing and Signal
Descriptions
This chapter provides the processor land assignment and signal descriptions.
4.1 Processor Land Assignments
This section contains the land listings for the Pentium 4 processor in the 775-land package. The
landout footprint is shown in Figure 4-1 and Figure 4-2. These figures represent the landout
arranged by land number and they show the physical location of each signal on the package land
array (top view). Table 4-1 is a listing of all processor lands ordered alphabetically by land (signal)
name. Table 4-2 is also a listing of all processor lands; the ordering is by land number.

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
