Land Listing and Signal Descriptions
56 Datasheet
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
A2 VSS Power/Other
A3 RS2# Common Clock Input
A4 D2# Source Synch Input/Output
A5 D4# Source Synch Input/Output
A6 VSS Power/Other
A7 D7# Source Synch Input/Output
A8 DBI0# Source Synch Input/Output
A9 VSS Power/Other
A10 D8# Source Synch Input/Output
A11 D9# Source Synch Input/Output
A12 VSS Power/Other
A13 COMP0 Power/Other Input
A14 D50# Source Synch Input/Output
A15 VSS Power/Other
A16 DSTBN3# Source Synch Input/Output
A17 D56# Source Synch Input/Output
A18 VSS Power/Other
A19 D61# Source Synch Input/Output
A20 RESERVED
A21 VSS Power/Other
A22 D62# Source Synch Input/Output
A23 VCCA Power/Other
A24 VSS Power/Other
A25 VTT Power/Other
A26 VTT Power/Other
A27 VTT Power/Other
A28 VTT Power/Other
A29 VTT Power/Other
A30 VTT Power/Other
B1 VSS Power/Other
B2 DBSY# Common Clock Input/Output
B3 RS0# Common Clock Input
B4 D0# Source Synch Input/Output
B5 VSS Power/Other
B6 D5# Source Synch Input/Output
B7 D6# Source Synch Input/Output
B8 VSS Power/Other
B9 DSTBP0# Source Synch Input/Output
B10 D10# Source Synch Input/Output
B11 VSS Power/Other
B12 D13# Source Synch Input/Output
B13 RESERVED
B14 VSS Power/Other
B15 D53# Source Synch Input/Output
B16 D55# Source Synch Input/Output
B17 VSS Power/Other
B18 D57# Source Synch Input/Output
B19 D60# Source Synch Input/Output
B20 VSS Power/Other
B21 D59# Source Synch Input/Output
B22 D63# Source Synch Input/Output
B23 VSSA Power/Other
B24 VSS Power/Other
B25 VTT Power/Other
B26 VTT Power/Other
B27 VTT Power/Other
B28 VTT Power/Other
B29 VTT Power/Other
B30 VTT Power/Other
C1 DRDY# Common Clock Input/Output
C2 BNR# Common Clock Input/Output
C3 LOCK# Common Clock Input/Output
C4 VSS Power/Other
C5 D1# Source Synch Input/Output
C6 D3# Source Synch Input/Output
C7 VSS Power/Other
C8 DSTBN0# Source Synch Input/Output
C9 RESERVED
C10 VSS Power/Other
C11 D11# Source Synch Input/Output
C12 D14# Source Synch Input/Output
C13 VSS Power/Other
C14 D52# Source Synch Input/Output
C15 D51# Source Synch Input/Output
C16 VSS Power/Other
C17 DSTBP3# Source Synch Input/Output
C18 D54# Source Synch Input/Output
C19 VSS Power/Other
C20 DBI3# Source Synch Input/Output
C21 D58# Source Synch Input/Output
C22 VSS Power/Other
C23 VCCIOPLL Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
