Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU User Manual

Land Listing and Signal Descriptions
Datasheet 57
C24 VSS Power/Other
C25 VTT Power/Other
C26 VTT Power/Other
C27 VTT Power/Other
C28 VTT Power/Other
C29 VTT Power/Other
C30 VTT Power/Other
D1 RESERVED
D2 ADS# Common Clock Input/Output
D3 VSS Power/Other
D4 HIT# Common Clock Input/Output
D5 VSS Power/Other
D6 VSS Power/Other
D7 D20# Source Synch Input/Output
D8 D12# Source Synch Input/Output
D9 VSS Power/Other
D10 D22# Source Synch Input/Output
D11 D15# Source Synch Input/Output
D12 VSS Power/Other
D13 D25# Source Synch Input/Output
D14 RESERVED
D15 VSS Power/Other
D16 RESERVED
D17 D49# Source Synch Input/Output
D18 VSS Power/Other
D19 DBI2# Source Synch Input/Output
D20 D48# Source Synch Input/Output
D21 VSS Power/Other
D22 D46# Source Synch Input/Output
D23 RESERVED
D24 VSS Power/Other
D25 VTT Power/Other
D26 VTT Power/Other
D27 VTT Power/Other
D28 VTT Power/Other
D29 VTT Power/Other
D30 VTT Power/Other
E2 VSS Power/Other
E3 TRDY# Common Clock Input
E4 HITM# Common Clock Input/Output
E5 RESERVED
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
E6 RESERVED
E7 RESERVED
E8 VSS Power/Other
E9 D19# Source Synch Input/Output
E10 D21# Source Synch Input/Output
E11 VSS Power/Other
E12 DSTBP1# Source Synch Input/Output
E13 D26# Source Synch Input/Output
E14 VSS Power/Other
E15 D33# Source Synch Input/Output
E16 D34# Source Synch Input/Output
E17 VSS Power/Other
E18 D39# Source Synch Input/Output
E19 D40# Source Synch Input/Output
E20 VSS Power/Other
E21 D42# Source Synch Input/Output
E22 D45# Source Synch Input/Output
E23 RESERVED
E24 RESERVED
E25 VSS Power/Other
E26 VSS Power/Other
E27 VSS Power/Other
E28 VSS Power/Other
E29 VSS Power/Other
F2 FC5 Common Clock Input
F3 BR0# Common Clock Input/Output
F4 VSS Power/Other
F5 RS1# Common Clock Input
F6 RESERVED
F7 VSS Power/Other
F8 D17# Source Synch Input/Output
F9 D18# Source Synch Input/Output
F10 VSS Power/Other
F11 D23# Source Synch Input/Output
F12 D24# Source Synch Input/Output
F13 VSS Power/Other
F14 D28# Source Synch Input/Output
F15 D30# Source Synch Input/Output
F16 VSS Power/Other
F17 D37# Source Synch Input/Output
F18 D38# Source Synch Input/Output
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
