Land Listing and Signal Descriptions
58 Datasheet
F19 VSS Power/Other
F20 D41# Source Synch Input/Output
F21 D43# Source Synch Input/Output
F22 VSS Power/Other
F23 RESERVED
F24 TESTHI7 Power/Other Input
F25 TESTHI2 Power/Other Input
F26 TESTHI0 Power/Other Input
F28 BCLK0 Clock Input
F29 RESERVED
G1 VSS Power/Other
G2 FC1 Power/Other Input
G3 TESTHI8 Power/Other Input
G4 TESTHI9 Power/Other Input
G5 FC7 Source Synch Output
G6 RESERVED
G7 DEFER# Common Clock Input
G8 BPRI# Common Clock Input
G9 D16# Source Synch Input/Output
G10 RESERVED
G11 DBI1# Source Synch Input/Output
G12 DSTBN1# Source Synch Input/Output
G13 D27# Source Synch Input/Output
G14 D29# Source Synch Input/Output
G15 D31# Source Synch Input/Output
G16 D32# Source Synch Input/Output
G17 D36# Source Synch Input/Output
G18 D35# Source Synch Input/Output
G19 DSTBP2# Source Synch Input/Output
G20 DSTBN2# Source Synch Input/Output
G21 D44# Source Synch Input/Output
G22 D47# Source Synch Input/Output
G23 RESET# Common Clock Input
G24 TESTHI6 Power/Other Input
G25 TESTHI3 Power/Other Input
G26 TESTHI5 Power/Other Input
G27 TESTHI4 Power/Other Input
G28 BCLK1 Clock Input
G29 BSEL0 Power/Other Output
G30 BSEL2 Power/Other Output
H1 GTLREF Power/Other Input
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
H2 FC6 Power/Other Input
H3 VSS Power/Other
H4 RSP# Common Clock Input
H5 TESTHI10 Power/Other Input
H6 VSS Power/Other
H7 VSS Power/Other
H8 VSS Power/Other
H9 VSS Power/Other
H10 VSS Power/Other
H11 VSS Power/Other
H12 VSS Power/Other
H13 VSS Power/Other
H14 VSS Power/Other
H15 DP1# Common Clock Input/Output
H16 DP2# Common Clock Input/Output
H17 VSS Power/Other
H18 VSS Power/Other
H19 VSS Power/Other
H20 VSS Power/Other
H21 VSS Power/Other
H22 VSS Power/Other
H23 VSS Power/Other
H24 VSS Power/Other
H25 VSS Power/Other
H26 VSS Power/Other
H27 VSS Power/Other
H28 VSS Power/Other
H29 GTLREF_SEL Power/Other Output
H30 BSEL1 Power/Other Output
J1 VTT_OUT_LEFT Power/Other Output
J2 FC3 Power/Other Input
J3 RESERVED
J4 VSS Power/Other
J5 REQ1# Source Synch Input/Output
J6 REQ4# Source Synch Input/Output
J7 VSS Power/Other
J8 VCC Power/Other
J9 VCC Power/Other
J10 VCC Power/Other
J11 VCC Power/Other
J12 VCC Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
