Land Listing and Signal Descriptions
Datasheet 59
J13 VCC Power/Other
J14 VCC Power/Other
J15 VCC Power/Other
J16 DP0# Common Clock Input/Output
J17 DP3# Common Clock Input/Output
J18 VCC Power/Other
J19 VCC Power/Other
J20 VCC Power/Other
J21 VCC Power/Other
J22 VCC Power/Other
J23 VCC Power/Other
J24 VCC Power/Other
J25 VCC Power/Other
J26 VCC Power/Other
J27 VCC Power/Other
J28 VCC Power/Other
J29 VCC Power/Other
J30 VCC Power/Other
K1 LINT0 Asynch GTL+ Input
K2 VSS Power/Other
K3 A20M# Asynch GTL+ Input
K4 REQ0# Source Synch Input/Output
K5 VSS Power/Other
K6 REQ3# Source Synch Input/Output
K7 VSS Power/Other
K8 VCC Power/Other
K23 VCC Power/Other
K24 VCC Power/Other
K25 VCC Power/Other
K26 VCC Power/Other
K27 VCC Power/Other
K28 VCC Power/Other
K29 VCC Power/Other
K30 VCC Power/Other
L1 LINT1 Asynch GTL+ Input
L2 TESTHI13 Asynch GTL+ Input
L3 VSS Power/Other
L4 A6# Source Synch Input/Output
L5 A3# Source Synch Input/Output
L6 VSS Power/Other
L7 VSS Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
L8 VCC Power/Other
L23 VSS Power/Other
L24 VSS Power/Other
L25 VSS Power/Other
L26 VSS Power/Other
L27 VSS Power/Other
L28 VSS Power/Other
L29 VSS Power/Other
L30 VSS Power/Other
M1 VSS Power/Other
M2 THERMTRIP# Asynch GTL+ Output
M3 STPCLK# Asynch GTL+ Input
M4 A7# Source Synch Input/Output
M5 A5# Source Synch Input/Output
M6 REQ2# Source Synch Input/Output
M7 VSS Power/Other
M8 VCC Power/Other
M23 VCC Power/Other
M24 VCC Power/Other
M25 VCC Power/Other
M26 VCC Power/Other
M27 VCC Power/Other
M28 VCC Power/Other
M29 VCC Power/Other
M30 VCC Power/Other
N1 PWRGOOD Power/Other Input
N2 IGNNE# Asynch GTL+ Input
N3 VSS Power/Other
N4 RESERVED
N5 RESERVED
N6 VSS Power/Other
N7 VSS Power/Other
N8 VCC Power/Other
N23 VCC Power/Other
N24 VCC Power/Other
N25 VCC Power/Other
N26 VCC Power/Other
N27 VCC Power/Other
N28 VCC Power/Other
N29 VCC Power/Other
N30 VCC Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
