Land Listing and Signal Descriptions
60 Datasheet
P1 TESTHI11 Power/Other Input
P2 SMI# Asynch GTL+ Input
P3 INIT# Asynch GTL+ Input
P4 VSS Power/Other
P5 RESERVED
P6 A4# Source Synch Input/Output
P7 VSS Power/Other
P8 VCC Power/Other
P23 VSS Power/Other
P24 VSS Power/Other
P25 VSS Power/Other
P26 VSS Power/Other
P27 VSS Power/Other
P28 VSS Power/Other
P29 VSS Power/Other
P30 VSS Power/Other
R1 FC2 Power/Other Input
R2 VSS Power/Other
R3 FERR#/PBE# Asynch GTL+ Output
R4 A8# Source Synch Input/Output
R5 VSS Power/Other
R6 ADSTB0# Source Synch Input/Output
R7 VSS Power/Other
R8 VCC Power/Other
R23 VSS Power/Other
R24 VSS Power/Other
R25 VSS Power/Other
R26 VSS Power/Other
R27 VSS Power/Other
R28 VSS Power/Other
R29 VSS Power/Other
R30 VSS Power/Other
T1 COMP1 Power/Other Input
T2 FC4 Power/Other Input
T3 VSS Power/Other
T4 A11# Source Synch Input/Output
T5 A9# Source Synch Input/Output
T6 VSS Power/Other
T7 VSS Power/Other
T8 VCC Power/Other
T23 VCC Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
T24 VCC Power/Other
T25 VCC Power/Other
T26 VCC Power/Other
T27 VCC Power/Other
T28 VCC Power/Other
T29 VCC Power/Other
T30 VCC Power/Other
U1 VSS Power/Other
U2 AP0# Common Clock Input/Output
U3 AP1# Common Clock Input/Output
U4 A13# Source Synch Input/Output
U5 A12# Source Synch Input/Output
U6 A10# Source Synch Input/Output
U7 VSS Power/Other
U8 VCC Power/Other
U23 VCC Power/Other
U24 VCC Power/Other
U25 VCC Power/Other
U26 VCC Power/Other
U27 VCC Power/Other
U28 VCC Power/Other
U29 VCC Power/Other
U30 VCC Power/Other
V1 MSID1 Power/Other Output
V2 LL_ID0 Power/Other Output
V3 VSS Power/Other
V4 A15# Source Synch Input/Output
V5 A14# Source Synch Input/Output
V6 VSS Power/Other
V7 VSS Power/Other
V8 VCC Power/Other
V23 VSS Power/Other
V24 VSS Power/Other
V25 VSS Power/Other
V26 VSS Power/Other
V27 VSS Power/Other
V28 VSS Power/Other
V29 VSS Power/Other
V30 VSS Power/Other
W1 MSID0 Power/Other Output
W2 TESTHI12 Power/Other Input
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
