Land Listing and Signal Descriptions
Datasheet 61
W3 TESTHI1 Power/Other Input
W4 VSS Power/Other
W5 A16# Source Synch Input/Output
W6 A18# Source Synch Input/Output
W7 VSS Power/Other
W8 VCC Power/Other
W23 VCC Power/Other
W24 VCC Power/Other
W25 VCC Power/Other
W26 VCC Power/Other
W27 VCC Power/Other
W28 VCC Power/Other
W29 VCC Power/Other
W30 VCC Power/Other
Y1 BOOTSELECT Power/Other Input
Y2 VSS Power/Other
Y3 RESERVED
Y4 A20# Source Synch Input/Output
Y5 VSS Power/Other
Y6 A19# Source Synch Input/Output
Y7 VSS Power/Other
Y8 VCC Power/Other
Y23 VCC Power/Other
Y24 VCC Power/Other
Y25 VCC Power/Other
Y26 VCC Power/Other
Y27 VCC Power/Other
Y28 VCC Power/Other
Y29 VCC Power/Other
Y30 VCC Power/Other
AA2 LL_ID1 Power/Other Output
AA3 VSS Power/Other
AA4 A21# Source Synch Input/Output
AA5 A23# Source Synch Input/Output
AA6 VSS Power/Other
AA7 VSS Power/Other
AA8 VCC Power/Other
AA23 VSS Power/Other
AA24 VSS Power/Other
AA25 VSS Power/Other
AA26 VSS Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
AA27 VSS Power/Other
AA28 VSS Power/Other
AA29 VSS Power/Other
AA30 VSS Power/Other
AB1 VSS Power/Other
AB2 IERR# Asynch GTL+ Output
AB3 MCERR# Common Clock Input/Output
AB4 A26# Source Synch Input/Output
AB5 A24# Source Synch Input/Output
AB6 A17# Source Synch Input/Output
AB7 VSS Power/Other
AB8 VCC Power/Other
AB23 VSS Power/Other
AB24 VSS Power/Other
AB25 VSS Power/Other
AB26 VSS Power/Other
AB27 VSS Power/Other
AB28 VSS Power/Other
AB29 VSS Power/Other
AB30 VSS Power/Other
AC1 TMS TAP Input
AC2 DBR# Power/Other Output
AC3 VSS Power/Other
AC4 RESERVED
AC5 A25# Source Synch Input/Output
AC6 VSS Power/Other
AC7 VSS Power/Other
AC8 VCC Power/Other
AC23 VCC Power/Other
AC24 VCC Power/Other
AC25 VCC Power/Other
AC26 VCC Power/Other
AC27 VCC Power/Other
AC28 VCC Power/Other
AC29 VCC Power/Other
AC30 VCC Power/Other
AD1 TDI TAP Input
AD2 BPM2# Common Clock Input/Output
AD3 BINIT# Common Clock Input/Output
AD4 VSS Power/Other
AD5 ADSTB1# Source Synch Input/Output
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
