Land Listing and Signal Descriptions
62 Datasheet
AD6 A22# Source Synch Input/Output
AD7 VSS Power/Other
AD8 VCC Power/Other
AD23 VCC Power/Other
AD24 VCC Power/Other
AD25 VCC Power/Other
AD26 VCC Power/Other
AD27 VCC Power/Other
AD28 VCC Power/Other
AD29 VCC Power/Other
AD30 VCC Power/Other
AE1 TCK TAP Input
AE2 VSS Power/Other
AE3 RESERVED
AE4 RESERVED
AE5 VSS Power/Other
AE6 RESERVED
AE7 VSS Power/Other
AE8 SKTOCC# Power/Other Output
AE9 VCC Power/Other
AE10 VSS Power/Other
AE11 VCC Power/Other
AE12 VCC Power/Other
AE13 VSS Power/Other
AE14 VCC Power/Other
AE15 VCC Power/Other
AE16 VSS Power/Other
AE17 VSS Power/Other
AE18 VCC Power/Other
AE19 VCC Power/Other
AE20 VSS Power/Other
AE21 VCC Power/Other
AE22 VCC Power/Other
AE23 VCC Power/Other
AE24 VSS Power/Other
AE25 VSS Power/Other
AE26 VSS Power/Other
AE27 VSS Power/Other
AE28 VSS Power/Other
AE29 VSS Power/Other
AE30 VSS Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
AF1 TDO TAP Output
AF2 BPM4# Common Clock Input/Output
AF4 A28# Source Synch Input/Output
AF5 A27# Source Synch Input/Output
AF6 VSS Power/Other
AF7 VSS Power/Other
AF8 VCC Power/Other
AF9 VCC Power/Other
AF10 VSS Power/Other
AF11 VCC Power/Other
AF12 VCC Power/Other
AF13 VSS Power/Other
AF14 VCC Power/Other
AF15 VCC Power/Other
AF16 VSS Power/Other
AF17 VSS Power/Other
AF18 VCC Power/Other
AF19 VCC Power/Other
AF20 VSS Power/Other
AF21 VCC Power/Other
AF22 VCC Power/Other
AF23 VSS Power/Other
AF24 VSS Power/Other
AF25 VSS Power/Other
AF26 VSS Power/Other
AF27 VSS Power/Other
AF28 VSS Power/Other
AF29 VSS Power/Other
AF3 VSS Power/Other
AF30 VSS Power/Other
AG1 TRST# TAP Input
AG2 BPM3# Common Clock Input/Output
AG3 BPM5# Common Clock Input/Output
AG4 A30# Source Synch Input/Output
AG5 A31# Source Synch Input/Output
AG6 A29# Source Synch Input/Output
AG7 VSS Power/Other
AG8 VCC Power/Other
AG9 VCC Power/Other
AG10 VSS Power/Other
AG11 VCC Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
