Land Listing and Signal Descriptions
Datasheet 63
AG12 VCC Power/Other
AG13 VSS Power/Other
AG14 VCC Power/Other
AG15 VCC Power/Other
AG16 VSS Power/Other
AG17 VSS Power/Other
AG18 VCC Power/Other
AG19 VCC Power/Other
AG20 VSS Power/Other
AG21 VCC Power/Other
AG22 VCC Power/Other
AG23 VSS Power/Other
AG24 VSS Power/Other
AG25 VCC Power/Other
AG26 VCC Power/Other
AG27 VCC Power/Other
AG28 VCC Power/Other
AG29 VCC Power/Other
AG30 VCC Power/Other
AH1 VSS Power/Other
AH2 RESERVED
AH3 VSS Power/Other
AH4 A32# Source Synch Input/Output
AH5 A33# Source Synch Input/Output
AH6 VSS Power/Other
AH7 VSS Power/Other
AH8 VCC Power/Other
AH9 VCC Power/Other
AH10 VSS Power/Other
AH11 VCC Power/Other
AH12 VCC Power/Other
AH13 VSS Power/Other
AH14 VCC Power/Other
AH15 VCC Power/Other
AH16 VSS Power/Other
AH17 VSS Power/Other
AH18 VCC Power/Other
AH19 VCC Power/Other
AH20 VSS Power/Other
AH21 VCC Power/Other
AH22 VCC Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
AH23 VSS Power/Other
AH24 VSS Power/Other
AH25 VCC Power/Other
AH26 VCC Power/Other
AH27 VCC Power/Other
AH28 VCC Power/Other
AH29 VCC Power/Other
AH30 VCC Power/Other
AJ1 BPM1# Common Clock Input/Output
AJ2 BPM0# Common Clock Input/Output
AJ3 ITP_CLK1 TAP Input
AJ4 VSS Power/Other
AJ5 A34# Source Synch Input/Output
AJ6 A35# Source Synch Input/Output
AJ7 VSS Power/Other
AJ8 VCC Power/Other
AJ9 VCC Power/Other
AJ10 VSS Power/Other
AJ11 VCC Power/Other
AJ12 VCC Power/Other
AJ13 VSS Power/Other
AJ14 VCC Power/Other
AJ15 VCC Power/Other
AJ16 VSS Power/Other
AJ17 VSS Power/Other
AJ18 VCC Power/Other
AJ19 VCC Power/Other
AJ20 VSS Power/Other
AJ21 VCC Power/Other
AJ22 VCC Power/Other
AJ23 VSS Power/Other
AJ24 VSS Power/Other
AJ25 VCC Power/Other
AJ26 VCC Power/Other
AJ27 VSS Power/Other
AJ28 VSS Power/Other
AJ29 VSS Power/Other
AJ30 VSS Power/Other
AK1 THERMDC Power/Other
AK2 VSS Power/Other
AK3 ITP_CLK0 TAP Input
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
