Land Listing and Signal Descriptions
Datasheet 53
VSS AJ23 Power/Other
VSS AJ24 Power/Other
VSS AJ27 Power/Other
VSS AJ28 Power/Other
VSS AJ29 Power/Other
VSS AJ30 Power/Other
VSS AJ4 Power/Other
VSS AJ7 Power/Other
VSS AK10 Power/Other
VSS AK13 Power/Other
VSS AK16 Power/Other
VSS AK17 Power/Other
VSS AK2 Power/Other
VSS AK20 Power/Other
VSS AK23 Power/Other
VSS AK24 Power/Other
VSS AK27 Power/Other
VSS AK28 Power/Other
VSS AK29 Power/Other
VSS AK30 Power/Other
VSS AK5 Power/Other
VSS AK7 Power/Other
VSS AL10 Power/Other
VSS AL13 Power/Other
VSS AL16 Power/Other
VSS AL17 Power/Other
VSS AL20 Power/Other
VSS AL23 Power/Other
VSS AL24 Power/Other
VSS AL27 Power/Other
VSS AL28 Power/Other
VSS AL3 Power/Other
VSS AL7 Power/Other
VSS AM1 Power/Other
VSS AM10 Power/Other
VSS AM13 Power/Other
VSS AM16 Power/Other
VSS AM17 Power/Other
VSS AM20 Power/Other
VSS AM23 Power/Other
Table 4-1. Alphabetical Land
Assignments
Land Name
Land
#
Signal Buffer
Type
Direction
VSS AM24 Power/Other
VSS AM27 Power/Other
VSS AM28 Power/Other
VSS AM4 Power/Other
VSS AN1 Power/Other
VSS AN10 Power/Other
VSS AN13 Power/Other
VSS AN16 Power/Other
VSS AN17 Power/Other
VSS AN2 Power/Other
VSS AN20 Power/Other
VSS AN23 Power/Other
VSS AN24 Power/Other
VSS AN27 Power/Other
VSS AN28 Power/Other
VSS B1 Power/Other
VSS B11 Power/Other
VSS B14 Power/Other
VSS B17 Power/Other
VSS B20 Power/Other
VSS B24 Power/Other
VSS B5 Power/Other
VSS B8 Power/Other
VSS C10 Power/Other
VSS C13 Power/Other
VSS C16 Power/Other
VSS C19 Power/Other
VSS C22 Power/Other
VSS C24 Power/Other
VSS C4 Power/Other
VSS C7 Power/Other
VSS D12 Power/Other
VSS D15 Power/Other
VSS D18 Power/Other
VSS D21 Power/Other
VSS D24 Power/Other
VSS D3 Power/Other
VSS D5 Power/Other
VSS D6 Power/Other
VSS D9 Power/Other
Table 4-1. Alphabetical Land
Assignments
Land Name
Land
#
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
