Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU User Manual

Land Listing and Signal Descriptions
Datasheet 65
AM27 VSS Power/Other
AM28 VSS Power/Other
AM29 VCC Power/Other
AM30 VCC Power/Other
AN1 VSS Power/Other
AN2 VSS Power/Other
AN3 VCC_SENSE Power/Other Output
AN4 VSS_SENSE Power/Other Output
AN5
VCC_MB_
REGULATION
Power/Other Output
AN6
VSS_MB_
REGULATION
Power/Other Output
AN7 FC16 Power/Other Output
AN8 VCC Power/Other
AN9 VCC Power/Other
AN10 VSS Power/Other
AN11 VCC Power/Other
AN12 VCC Power/Other
AN13 VSS Power/Other
AN14 VCC Power/Other
AN15 VCC Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction
AN16 VSS Power/Other
AN17 VSS Power/Other
AN18 VCC Power/Other
AN19 VCC Power/Other
AN20 VSS Power/Other
AN21 VCC Power/Other
AN22 VCC Power/Other
AN23 VSS Power/Other
AN24 VSS Power/Other
AN25 VCC Power/Other
AN26 VCC Power/Other
AN27 VSS Power/Other
AN28 VSS Power/Other
AN29 VCC Power/Other
AN30 VCC Power/Other
Table 4-2. Numerical Land Assignment
Land
#
Land Name
Signal Buffer
Type
Direction

Intel 520J - Pentium 4 2.80GHz 800MHz 1MB Socket 775 CPU Specifications

General

Clock Speed	2.80 GHz
Front Side Bus Speed	800 MHz
L2 Cache	1 MB
Socket Type	LGA 775
Core	Prescott
Lithography	90 nm
Thermal Design Power (TDP)	84 W
Instruction Set	x86
Virtualization Technology	No
64-bit Support	Yes
Hyper-Threading	Yes
Integrated Graphics	No
Processor Model	Intel Pentium 4 520J
Extensions	SSE2, SSE3
