Intel Bay Trail Series User Manual

24
EIST
The optional settings: [Enabled]; [Disabled].
Use this item to enable or disable Intel SpeedStep.
CPU C Status Report
The optional settings: [Disabled]; [Enabled].
Use this item to enable or disable CPU C status report to OS.
*When set as [Enabled], the following sub-items shall appear:
Max CPU C-state
This option controls Max C state that the processor will support.
The optional settings: [C7]; [C6]; [C1].
 SATA Configuration
Press [Enter] to make settings for the following sub-items:
SATA Configuration
SATA Port
The optional settings: [Disabled]; [Enabled].
Use this item to enable or disable Serial ATA port.
SATA Speed Support
The item is for user to set the maximum speed the SATA controller can support.
The optional settings are: [Gen1]; [Gen2].
SATA ODD Port
The optional settings are: [Port0 ODD]; [Port1 ODD]; [No ODD].
SATA Mode
The optional settings are: [IDE Mode]; [AHCI Mode].
SATA1 or MSATA
The optional settings are: [Enabled]; [Disabled].
Use this item to enable or disable SATA Port.
SATA1 or MSATA HotPlug
The optional settings are: [Enabled]; [Disabled].
Use this item to enable or disable support for SATA Port HotPlug function.
SATA2
The optional settings are: [Enabled]; [Disabled].
Use this item to enable or disable SATA Port.
SATA Port2 HotPlug
The optional settings are: [Enabled]; [Disabled].

Intel Bay Trail Series Specifications

General

Memory Type	DDR3L
Max Memory Size	8 GB
Graphics Output	HDMI, DisplayPort, VGA
USB Ports	USB 3.0, USB 2.0
SATA Ports	SATA 3.0
PCI Express Revision	2.0
TDP	4.5-10 W
Chipset	Integrated
