Intel BOXD525MW User Manual

Intel Desktop Board D525MW Product Guide
12
Table 2. Intel Desktop Board D525MW Components
Label Description
A Back panel connectors
B Serial header (COM1)
C Chassis fan header
D 12 V processor core voltage connector (2 x 2 pin)
E Processor
F Main power connector (2 x 12 pin)
G SO-DIMM 0 slot
H SO-DIMM 1 slot
I Battery
J SATA 1
K SATA 0
L USB front panel header
M Front panel header
N Standby power indicator
O BIOS configuration jumper block
P PCI Express Mini Card slot
Q Intel NM10 Express Chipset
R Front panel wireless activity LED header
S USB front panel header with Intel Z-U130 USB Solid-State Drive (or
compatible device) support
T PCI bus connector
U S/PDIF header
V Front panel audio header

Intel BOXD525MW Specifications

General

Brand	Intel
Model	BOXD525MW
Category	Motherboard
Language	English
