Intel BOXD525MW User Manual

Installing and Replacing Desktop Board Components
35
Connecting to the Serial Port Header
Before connecting to the serial port header, observe the precautions in "Before You
Begin" on page 23. See Figure 12, C on page 33 for the location of the serial port
header.
Table 8 shows the pin assignments for the seri
al port header.
Table 8. Serial Port Header (COM 1)
Pin Signal Name Pin Signal Name
1 DCD (Data Carrier Detect) 2 RXD# (Receive Data)
3 TXD# (Transmit Data) 4 DTR (Data Terminal Ready)
5 Ground 6 DSR (Data Set Ready)
7 RTS (Request To Send) 8 CTS (Clear To Send)
9 RI (Ring Indicator) 10 Key (no pin)
Connecting to the Front Panel USB 2.0 Headers
Before connecting to the USB 2.0 headers, observe the precautions in "Before You
Begin" on page 23. See Figure 12, D and G on page 33 for the location of the USB 2.0
headers. Table 9 and Table 10 show the pin assignments for the
headers.
The brown
USB header (Figure 12, G) supports a single USB port while the black USB
header (Fig
ure 12, D) supports two USB ports. The
single USB port header is
designed to support a Flash Memory Drive such as the Intel Z-U130 USB Solid-State
Drive (or compatible device). Refer to Installing an Intel
®
Z-U130 USB Solid-State
Drive or Compatible Device on page 32 for more information.
Table 9.
Front Panel USB Header
Pin Signal Name Pin Signal Name
1
+5 VDC
2
+5 VDC
3
D-
4
D-
5
D+
6
D+
7
Ground
8
Ground
9
KEY (no pin)
10
No Connect
Table 10. Front Panel USB Header with Intel Z-U130 USB Solid-State Drive or
Compatible Device Support
Pin Signal Name Pin Signal Name
1
+5 VDC
2
No Connect
3
D-
4
No Connect
5
D+
6
No Connect
7
Ground
8
No Connect
9
KEY (no pin)
10
LED#
