Intel Desktop Board D525MW Product Guide
36
Connecting to the Front Panel Header
Before connecting to the front panel header, observe the precautions in "Before You
Begin" on page 23. See Figure 12, E on page 33 for the location of the front panel
header.
Table 11 shows the pin assignments for th
e front panel header.
Table 11. Front Panel Header Signal Names
Pin Signal In/Out Description Pin Signal In/Out Description
Hard Drive Activity LED Power LED
1 HD_PWR Out
Hard disk LED pull-
up (330 Ω) to +5 V
2 HDR_BLNK_GRN Out
Front panel
green LED
3 HDA# Out
Hard disk active
LED
4 HDR_BLNK_YEL Out
Front panel
yellow LED
Reset Switch On/Off Switch
5 Ground Ground 6 SWITCH_ON# In Power switch
7 FP_RESET# In Reset switch 8 Ground Ground
Power Not Connected
9 +5 V Power 10 N/C No pin
Connecting to the Front Panel Wireless Activity LED
Header
Before connecting to the front panel wireless activity LED header, observe the
precautions in "Before You Begin" on page 23. See Figure 12, F on page 33 for the
lo
cation of the front panel wireless activity LED header.
Table 12 shows the pin assignments for the front panel wireless activity LED header.
Table 12. Front Panel Wireless Activity LED Header
Pin Signal Name
1 LED (+)
2 Ground
