Intel D525 User Manual

32
The optional settings are: [Disabled]; [3F8/IRQ4]; [3E8/IRQ4]; [2E8/IRQ3].
Serial Port 2 Address
This item allows BIOS to select base addresses for serial port 2.
The optional settings are: [Disabled]; [2F8/IRQ3]; [3E8/IRQ4]; [2E8/IRQ3].
Serial Port 3 Address
This item allows BIOS to select base addresses for serial port 3.
The optional settings are: [Disabled]; [3F8]; [2F8]; [3E8]; [2E8]; [4E0] [4E8].
Serial Port 3 IRQ
This item allows BIOS to select IRQ for serial port 3.
The optional settings are: [3]; [4]; [10]; [11].
Serial Port 4 Address
This item allows BIOS to select base addresses for serial port 4.
The optional settings are: [Disabled]; [3F8]; [2F8]; [3E8]; [2E8]; [4E0] [4E8].
Serial Port 4 IRQ
This item allows BIOS to select IRQ for serial port 4.
The optional settings are: [3]; [4]; [10]; [11].
Parallel Port Address
Use this item to allow BIOS to select parallel port base adresses.
The optional settings are: [Disabled]; [378]; [278]; [3BC].
Parallel Port Mode
The optional settings are: [Normal]; [Bi-Directional]; [ECP]; [EPP]; [ECP & EPP].
Watchdog Timer Select
This item is used to activate the watchdog function. The optional settings are: [Enabled];
[Disabled].
*Note: When set as Enabled, The following sub-items shall appear:
WatchDog Timer Val
User can type a number in the range of 4 to 255.
WatchDog Timer Unit
The optional settings are: [Sec.]; [Min.].

Intel D525 Specifications

General

CPU	Intel Atom D525
Memory Type	DDR3
Max Memory	4GB
Storage Interfaces	2 x SATA 3Gb/s
USB Ports	6 x USB 2.0
Form Factor	Mini-ITX
Memory Slots	2
Graphics	Intel GMA 3150
Expansion Slots	1 x PCI
Audio	Realtek ALC662
