Intel D525 User Manual

1
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard
z
Intel
®
ATOM D525 dual-core CPU+ Intel
®
NM10 express chipset, with low power
consumption never denies high performance
z
Support 1 * DDRIII SO-DIMM 800 MHz up to 4GB
z
Onboard RTL8111F Gigabit Ethernet LAN chip
z
Integrated ALC887 HD audio chip
z
Support half-size Mini-PCIE connector
z
Support USB 2.0 data transport demands
z
Support PCI slot and Mini-PCIE slot
z
Support m-SATA connector
z
Integrated with 18-bit single channel LVDS header
z
Support 1 * Serial ATAII (3Gb/s) Devices
z
Supports ACPI S3 Function
z
Support CPU Smart FAN
z
Support GPIO Technology
z
Support Thunder Protection Function
z
Compliance with EuP Standard
z
All Solid Capacitor design

Intel D525 Specifications

General

CPU	Intel Atom D525
Memory Type	DDR3
Max Memory	4GB
Storage Interfaces	2 x SATA 3Gb/s
USB Ports	6 x USB 2.0
Form Factor	Mini-ITX
Memory Slots	2
Graphics	Intel GMA 3150
Expansion Slots	1 x PCI
Audio	Realtek ALC662
