Intel Desktop Board D845EPI Technical Product Specification

Table 20. Rear Chassis Fan Connector

Pin Signal Name

1 Ground (default) or

FNT_REAR_FAN_CTRL (optional)

2 +12 V

3 No connect (default) or

REAR_TACH_OUT (optional)

Table 21. Processor Fan Connector

Pin Signal Name

1 Ground (default) or CPU_FAN_TACH

(optional)

2 +12 V

3 No connect (default) or

CPU_FAN_TACH

Table 22. Main Power Connector

Pin Signal Name Pin Signal Name

1 +3.3 V 11 +3.3 V

2 +3.3 V 12 -12 V

3 Ground 13 Ground

4 +5 V 14 PS-ON# (power supply remote on/off)

5 Ground 15 Ground

6 +5 V 16 Ground

7 Ground 17 Ground

8 PWRGD (Power Good) 18 No connect

9 +5 V (Standby) 19 +5 V

10 +12 V 20 +5 V

Table 23. Front Chassis Fan Connector

Pin Signal Name

1 Ground (default) or

FNT_REAR_FAN_CTRL (optional)

2 +12 V

3 No connect (default) or

FRONT_FAN_TACH (optional)

Table 24. Chassis Intrusion Connector

Pin Signal Name

1 Intruder

2 Ground
