Intel Desktop Board D845EPI Technical Product Specification
60
OM16251
A
D
B
C
Item Description
A Processor voltage regulator area
B Processor
C Intel 82845E MCH
D Intel 82801DB ICH4
Figure 13. Localized High Temperature Zones
Table 34 provides maximum case temperatures for Desktop Board D845EPI components that are
sensitive to thermal changes. The operating temperature, current load, or operating frequency
could affect case temperatures. Maximum case temperatures are important when considering
proper airflow to cool the Desktop Board D845EPI.
Table 34. Thermal Considerations for Components
Component Maximum Case Temperature
Intel Pentium 4 processor For processor case temperature, see processor datasheets and
processor specification updates
Intel 82845E MCH 92
o
C (under bias)
Intel 82801DB ICH4 110
o
C (under bias)
