Primary/Secondary IDE Master/Slave Submenus
Maintenance Main Advanced Security Power Boot Exit
IDE Configuration
➜
Primary IDE Master
Primary IDE Slave
Secondary IDE Master
Secondary IDE Slave
There are four IDE submenus: Primary master, primary slave, secondary master, and secondary
slave. Table 18 shows the format of these IDE submenus. For brevity, only one example
is shown.
Table 18. Primary/Secondary IDE Master/Slave Submenus
Feature Options Description
Drive Installed None Displays the type of drive installed.
Type
• Auto (default)
• User
Specifies the IDE configuration mode for IDE devices.
Auto fills-in capabilities from ATA/ATAPI device.
User allows capabilities to be changed.
Maximum Capacity None Displays the capacity of the drive.
LBA Mode Control
(Note)
None Specifies LBA mode control.
Block Mode • Disabled
• Auto (default)
Check the hard disk drive’s specifications for optimum
setting.
PIO Mode
(Note)
• Auto (default)
• 0
• 1
• 2
• 3
• 4
Specifies the PIO mode.
DMA Mode
• Auto (default)
• SWDMA 0
• SWDMA 1
• SWDMA 2
• MWDMA 0
• MWDMA 1
• MWDMA 2
• UDMA 0
• UDMA 1
• UDMA 2
• UDMA 3
• UDMA 4
• UDMA 5
Specifies the Ultra DMA mode for the drive.
S.M.A.R.T.
• Auto (default)
• Disable
• Enable
Self-monitoring analysis and reporting technology.
Cable Detected
(Note)
None Displays the type of cable connected to the IDE interface:
40-conductor or 80-conductor (for ATA-66/100 devices).
Note: These configuration options appear only if an IDE device is installed.
