7
1 Desktop Board Features
Table 1 describes the major features of Intel
®
Desktop Board D845GERG2/D845GEBV2.
Table 1. Feature Summary
Form Factors
• MicroATX at 9.6 inches by 8.2 inches (Desktop Board D845GERG2)
• ATX at 12.0 inches by 8.2 inches (Desktop Board D845GEBV2)
Processor
Support for:
• 533 MHz/400 MHz front side bus (FSB) Intel
®
Pentium
®
4 processor in an
mPGA-478 socket
• 400 MHz FSB Intel
®
Celeron
®
processor in an mPGA-478 socket
Memory
• Two 184-pin, 2.5 V SDRAM Dual Inline Memory Module (DIMM) sockets
• 333/266 MHz DDR SDRAM interface
• Designed to support up to 2 GB of system memory
NOTE: Desktop Board D845GERG2/D845GEBV2 has been designed to support DIMMs
based on 512 Mbit technology up to 2 GB, but this technology has not been validated on
these Intel desktop boards. For more information about the latest list of tested memory,
refer to the Intel World Wide Web site at:
http://support.intel.com/support/motherboards/desktop/
Chipset
• Intel
®
845GE chipset consisting of:
• Intel
®
82845GE Graphics and Memory Controller Hub (GMCH) with
Accelerated Hub Architecture (AHA) bus
• Intel
®
82801DB I/O Controller Hub (ICH4) with support for up to six
Hi-Speed Universal Serial Bus 2.0 (USB 2.0) ports
• 4 Mbit Firmware Hub (FWH)
I/O Control
Support for:
• SMSC LPC47M172
• National Semiconductor PC87372
Graphics
• Intel 845GE chipset
• Integrated Intel
®
Extreme Graphics
• 1.5 V AGP connector
• Single AGP port via the connector or integrated graphics
• AGP 2.0 including 1x/2x/4x AGP data transfers and 2x/4x Fast Writes
• 350 MHz AGP Digital Display (ADD) interface cards
Audio
• Intel 845GE chipset (AC ’97)
• Analog Devices Inc. audio codec
LAN (optional)
• Intel
®
82562ET 10/100 Mbit/sec Platform LAN Connect (PLC) device and
RJ-45 connector
• Intel
®
82540EM 10/100/1000 Mbit/sec Gigabit Ethernet controller
continued
