Intel Desktop Board D845GERG2/D845GEBV2 Product Guide
8
Table 1. Feature Summary (continued)
Peripheral Interfaces
• Up to six USB 2.0 ports
— Four ports routed to the back panel
— Two ports routed to the front panel USB header
• Two IDE interfaces with Ultra DMA-33 and ATA-66/100 support
• One diskette drive interface
• One parallel port
• One serial port
• PS/2
†
keyboard and mouse ports
Expansion Capabilities
• Desktop Board D845GERG2:
— Three PCI bus add-in card connectors
— One AGP connector
— One optional Communication and Networking Riser (CNR) connector
(slot shared with PCI bus connector 3)
• Desktop Board D845GEBV2:
— Six PCI bus add-in card connectors
— One AGP connector
One optional CNR connector (slot shared with PCI bus connector 6)
BIOS
• Intel/AMI BIOS
• 4 Mbit symmetrical flash memory
• Support for SMBIOS
Power Management
• Support for Advanced Configuration and Power Interface (ACPI)
• Suspend to RAM (STR) support
• Wake on USB, PCI, CNR, RS-232, PS/2, LAN, and front panel
Hardware Management
Hardware monitor with:
• Three fan sensing inputs used to monitor fan activity
• Temperature sensing
• Intel
®
Precision Cooling Technology fan speed control that automatically
adjusts chassis fan speeds based on system temperature
• Voltage sensing to detect out of range values
✏
NOTE
For information about Intel
®
desktop boards, including technical product specifications, BIOS
updates, and device drivers, go to the Intel World Wide Web site at:
http://support.intel.com/support/motherboards/desktop/
