Intel DESKTOP BOARD D955XBK - Component-Side Connectors Shown in Figure 19

Technical Reference
57
Table 17. Component-side Connectors Shown in Figure 19
Item/callout from Figure 19 Description
A
PCI Express x1 bus add-in card connector
B
Auxiliary rear fan connector
C
PCI Conventional bus add-in card connector 3
D
ATAPI CD-ROM connector (optional)
E
PCI Conventional bus add-in card connector 2
F
PCI Conventional bus add-in card connector 1
G
Front panel audio connector
H
Secondary PCI Express x16/x4 bus add-in card connector
I
PCI Express x16 bus add-in card connector
J
Alternate power connector (optional)
K
Rear chassis fan connector
L
Processor power connector
M
Processor fan connector
N
Power connector
O
Diskette drive connector
P
Parallel ATA IDE connector
Q
Front chassis fan connector
R
Chassis intrusion connector
S
Serial ATA connector 3 (ICH7-R RAID)
T
Serial ATA connector 2 (ICH7-R RAID)
U
Serial ATA connector 0 (ICH7-R RAID)
V
Serial ATA connector 1 (ICH7-R RAID)
W
Auxiliary front panel power LED connector
X
Front panel connector
Y
Front panel USB connector
Z
Auxiliary power output connector (optional)
AA
SCSI hard drive activity indicator LED (optional)
BB
Serial ATA connector 7 (Discrete RAID) (optional)
CC
Serial ATA connector 6 (Discrete RAID) (optional)
DD
Serial ATA connector 4 (Discrete RAID) (optional)
EE
Serial ATA connector 5 (Discrete RAID) (optional)
FF
Front panel IEEE-1394a/b connector [pink] (optional)
GG
Front panel IEEE-1394a/b connector [blue] (optional)
HH
Front panel USB connector
