Intel Desktop Board D955XBK Technical Product Specification
74
OM17724
B
A
CD
Item Description
A Processor voltage regulator area
B Processor
C Intel 82955X MCH
D Intel 82801GR ICH7-R
Figure 28. Localized High Temperature Zones
CAUTION
Ensure that the ambient temperature does not exceed the board’s maximum operating temperature.
Failure to do so could cause components to exceed their maximum case temperature and
malfunction. For information about the maximum operating temperature, see the environmental
specifications in Section 2.13.
